CP654ULHTSP Plenum Rated Condensate Pump 460V, 65 foot Max Lift

$729.89

Beckett’s heavy-duty pump series is capable of handling all your high lift industrial applications. It features a reliable two float design as well as our most powerful motors that maintain our proven durability. Power is supplied with a hard-wired terminal block. Ideal solution for high lift installations up to 65’ lift. Rated for condensate applications with water temperature up to 212° F.

Description

Beckett’s heavy-duty CP654ULHTSP large plenum rated condensate pump designed to be installed in plenum locations and handles condensate up to 212° F. This robust pump includes a reliable two float design as well as one of our largest motors to ensure efficient and quiet operation, plus long term durability. The ideal solution for high lift installations up to 65’ lift with AC units, humidifiers, dehumidifiers, high-efficiency furnaces, boilers, and other equipment. The pump has a built-in safety switch, a one-gallon tank, a replaceable check valve, and a pre-wired terminal block. This unit is also capable of handling high-acidity condensation. All CB65 condensate pumps are UL/CUL listed.

  • Pump is rated 460V, 60 Hz, 390 watts
  • With Safety Switch
  • 65 ft. max lift (High Head)
  • UL tested to UL2043 for Plenum Applications
  • Pump rated for water temperatures up to 212 degrees F
  • Normally in stock at our distributor. Email for lead time. Handling time normally 1–5 days.

Additional information

Weight 20 lbs
Dimensions 14 × 14 × 6 in
Pump Voltage

460 Volts

Condition

New

Manufacturer

Beckett

Pump options accessories

High Temperature Rated, With Safety Switch, Plenum Rated

Sump size

1 Gallon

Reviews

There are no reviews yet.


Be the first to review “CP654ULHTSP Plenum Rated Condensate Pump 460V, 65 foot Max Lift”

Instruction Manual

Download

Spec Sheet

Download
